32MP 128-Channel Network Video Recorder with 16 Hard Drive Bays (U2-NVR128ER)
Translation missing: en.products.product.sku: SKU# 3962NB
Order within to ship Login for better priceCouldn't load pickup availability
Choose a version
Choose between the Retail and Blank version of this product.
- UNV Retail versions come with the standard Uniview Product that has a Uniview Logo and Uniview Color Box.
- UNV Blank versions are Uniview product without any Uniview Logos on the product or the box. Only choose this option if you are one of our branding program customers.
NVR516-128E-R (NB)
Recorder
32MP
Up to 32MP Resolution
16 SATA HDD
Up to 16TB each
3 Year Warranty
Warranty Information
Features
- Supports Ultra 265/H.265/H.264 video formats
- 64/128-channel input
- Supports mainstream cameras of ONVIF conformance(Profile S, Profile G, Profile T ) and RTSP protocols
- Support 2-ch HDMI, 2-ch VGA, HDMI1 at up to 8K(7680x4320) resolution, HDMI2 at up to 4K(3840x2160) resolution
- VGA1 and HDMI1 simultaneous output, VGA2 and HDMI2 simultaneous output.
- VGA1/HDMI1 and VGA2/HDMI2 independent output
- Up to 32 Megapixels resolution recording
- Redundant power supply optional
- Supports HDD hot swap with RAID 0, 1, 5, 6, 10, 50, 60 storage scheme configurable
- Supports 12V power output
- ANR technology to enhance the storage reliability when the network is disconnected
- Supports cloud upgrade
- Supports N+1 Hot spare
Features
- Supports Ultra 265/H.265/H.264 video formats
- 64/128-channel input
- Supports mainstream cameras of ONVIF conformance(Profile S, Profile G, Profile T ) and RTSP protocols
- Support 2-ch HDMI, 2-ch VGA, HDMI1 at up to 8K(7680x4320) resolution, HDMI2 at up to 4K(3840x2160) resolution
- VGA1 and HDMI1 simultaneous output, VGA2 and HDMI2 simultaneous output.
- VGA1/HDMI1 and VGA2/HDMI2 independent output
- Up to 32 Megapixels resolution recording
- Redundant power supply optional
- Supports HDD hot swap with RAID 0, 1, 5, 6, 10, 50, 60 storage scheme configurable
- Supports 12V power output
- ANR technology to enhance the storage reliability when the network is disconnected
- Supports cloud upgrade
- Supports N+1 Hot spare
The NVR516-128E-R (NB) is just what your system needs to ensure fast, powerful, and reliable surveillance 24/7.
Please note, this recorder does not have an integrated PoE switch. Click here to shop external PoE switches.
Recording Schedules
If you want 24/7 video recording, the NVR516-128E-R (NB) NVR is a great choice. You can rest assured that your surveillance system never misses a moment with it's ability to add 16 Hard Drive/s, Up to 16TB each.
You can also setup custom recording schedules based on days and times of the week, or based on events such as motion detection.
NDAA Compliant
This model is compliant with the NDAA (National Defense Authorization Act), meaning it's safe to use and install on U.S. government properties. It was constructed with trusted and reliable technology at its core.
| SPECIFICATION | |
|---|---|
| IP Channels | 128 |
| Max Resolution | 32MP |
| Max Incoming Bandwidth | 640Mbps |
| Max Outgoing Bandwidth | 640Mbps |
| Hard Drive Slots | 16 |
| Hard Drive Capacity | Up to 16TB each |
| Synchronus Playback | 16ch |
| Alarm I/O | 16ch / 10ch |
| Power Supply | AC100 ~ 240V |
| Power Consumption | ≤ 50W |
| Operating Temperature | 14°F ~ 131°F |
| Dimensions | 19.0"×21.0"×5.1" |
| Weight | ~14.3lbs |
| SOFTWARE | |||
|---|---|---|---|
| Name | Description | Version | Download |
| Name Guard Station | Unified management for IP Cameras and NVRs. |
Version v1130.3.15.5
|
DownloadDownload |
| Name Guard Tools | Tool kit for device search and upgrade, remote configuration, recording time and capacity calculation. |
Version v1103
|
DownloadDownload |
| Name Guard Player | Media player for local recordings. |
Version v1111.1.1.0
|
DownloadDownload |
| Name Guard Station | Unified management for IP Cameras and NVRs. |
Versionv1113.3.10.1
|
DownloadDownload |
