Uniview by Uniview

UNV Pigtail-Free Indoor NDAA-Compliant 4MP Mini Dome IP Security Camera with a 2.8mm Fixed Lens, LightHunter Illumination, and a Built-In Mic (IPC354SB-ADNF28K-I0)

|

SKU# 3400

Order within to ship
$409.00
Login for better price
  • High quality image with 4MP, 1/2.7"CMOS sensor
  • 4MP (2688 x 1520)@ 30/25fps; 4MP (2560 x 1440)@ 30/25fps; 3MP (2304 x 1296) @30/25fps; 2MP (1920 x 1080) @30/25fps;
  • Ultra 265, H.265, H.264, MJPEG
  • 120dB true WDR technology enables clear image in strong light scene
  • Support 9:16 Corridor Mode
  • Built-in Mic
  • Smart IR, up to 98 ft IR distance
  • Supports 256 GB Micro SD card
  • Pigtail-free
  • Support PoE power supply

You may want these accessories for this product

UNV Wall Mount for Dome Security C...
$25.00

UNV Wall Mount W/ Junction Box for...
$40.00

UNV Junction Box for Fixed Lens Do...
$17.00

UNV Fixed Dome Indoor Incline Moun...
$4.00

UNV Pole Mount Adapter (TR-UP06-IN)
$17.00

UNV Waterproof Cable Joint (TR-A01...
$6.00

UNV Corner Bracket Mount for Bulle...
$26.00

IPC354SB-ADNF28K-I0

IP Security Camera

4MP

HD resolution

2.8mm

Fixed Lens

Up to 100ft

Night Vision IR Range

3 Year Warranty

Warranty Information

Characteristics

Tired of long and annoying cable pigtails getting in your way? Are you looking for a quick, simple, and streamlined installation process? Uniview’s cable-free vandal domes just may be the cameras that you’re looking for.

This 4MP indoor vandal dome is compact, lightweight, and easy to install. This camera is so small it could fit into your pocket! It’s the perfect camera when you need a small, inconspicuous solution for your indoor surveillance. It won’t draw unwanted attention and it won’t stand out like a sore thumb. The fact that this camera has no long cable pigtail makes it that much more efficient when it comes to space. Simply run your cables directly under the dome and plug them into the connections integrated into the camera’s body.

Integrated connections include an RJ45 port for your Ethernet cable, a 12V DC terminal, and wiring terminals for audio and alarm cables.

Speaking of audio, this camera also has a built-in microphone for instant audio surveillance with no additional configuration and no additional hardware. Simply turn on the audio from your NVR or from your camera’s interface and start recording audio right away.

This camera also has a slot for a microSD card, so you can set this up as a standalone camera and record directly to the memory card. Or you can set this up with your current system and use an SD card for backup.

Now integrated with Deep Learning artificial intelligence and new intelligent events, your pigtail-free camera is more powerful than ever before. With people counting, face detection, and human and vehicle detection, your camera is customizable enough to fit a variety of scenarios.

You can now experience the power and usability of Uniview without the frustration of a cable connection pigtail! Keep reading about the specs of this camera to see if this is the perfect solution for you.

Pigtail-Free

Pigtail-Free

This camera has no annoying cable pigtail, unlike most standard security cameras. Instead, all the connections are integrated into the camera's body. This leads to cleaner and more efficient installations, as well as a smaller form factor than most cameras.

Characteristics

Tired of long and annoying cable pigtails getting in your way? Are you looking for a quick, simple, and streamlined installation process? Uniview’s cable-free vandal domes just may be the cameras that you’re looking for.

This 4MP indoor vandal dome is compact, lightweight, and easy to install. This camera is so small it could fit into your pocket! It’s the perfect camera when you need a small, inconspicuous solution for your indoor surveillance. It won’t draw unwanted attention and it won’t stand out like a sore thumb. The fact that this camera has no long cable pigtail makes it that much more efficient when it comes to space. Simply run your cables directly under the dome and plug them into the connections integrated into the camera’s body.

Integrated connections include an RJ45 port for your Ethernet cable, a 12V DC terminal, and wiring terminals for audio and alarm cables.

Speaking of audio, this camera also has a built-in microphone for instant audio surveillance with no additional configuration and no additional hardware. Simply turn on the audio from your NVR or from your camera’s interface and start recording audio right away.

This camera also has a slot for a microSD card, so you can set this up as a standalone camera and record directly to the memory card. Or you can set this up with your current system and use an SD card for backup.

Now integrated with Deep Learning artificial intelligence and new intelligent events, your pigtail-free camera is more powerful than ever before. With people counting, face detection, and human and vehicle detection, your camera is customizable enough to fit a variety of scenarios.

You can now experience the power and usability of Uniview without the frustration of a cable connection pigtail! Keep reading about the specs of this camera to see if this is the perfect solution for you.

Pigtail-Free

Pigtail-Free

This camera has no annoying cable pigtail, unlike most standard security cameras. Instead, all the connections are integrated into the camera's body. This leads to cleaner and more efficient installations, as well as a smaller form factor than most cameras.

4MP HD RESOLUTION

The IPC354SB-ADNF28K-I0 captures video up to a resolution of 4MP @ 30 FPS, which is 2688 x 1520 pixels. Every pixel added to your camera's picture gives you a higher quality and more details. So at 4MP, your going to get a crisper, cleaner, and more detailed image.

2.8mm Fixed Lens

The IPC354SB-ADNF28K-I0 has a 2.8mm Fixed Lens. That means it's fixed at one length: it can't optically zoom in and out. The longer the focal length on a fixed lens camera, the more zoomed in it is and the more close-up detail you'll be able to see. But the shorter the focal length, the wider the field of view and the more area your surveillance will cover.

The IPC354SB-ADNF28K-I0 has a horizontal field of view of 101.1°.

Built-in Microphone

Having audio capabilities in your video surveillance system can be an important feature. The IPC354SB-ADNF28K-I0 comes with a built-in microphone, allowing you to hear and record crisp, clear audio without running any additional cables to power a microphone.

NDAA Compliant

This model is compliant with the NDAA (National Defense Authorization Act), meaning it's safe to use and install on U.S. government properties. It was constructed with trusted and reliable technology at its core.

Up to 100ft NIGHT VISION IR RANGE

When the sun goes down or the lights go out, this camera switches on it's own onboard infrared LED lights. Theses lights, which are invisible to the human eye, allow the camera to continue functioning and recording video 24/7, day or night. And since its IR range covers Up to 100ft, you're not going to miss anything that happens on your camera's feeds, even if it happens in pitch-black darkness.

Remote access Uniview

The IPC354SB-ADNF28K-I0 is part of the Uniview line of products. As such it's packed withfeatures that would please a power user, yet it's simple enough to operate for a novice. Easily view and manage your cameras and recorders anywhere in the world with the free mobile and desktop applications. For the power user, this app gives you the power to adjust advanced settings on fly. For the novice, you can use the apps to simply view live feeds and play back recorded video.


Plug & play

If you're creating a new system out of our Uniview cameras, set up is insanely easy with our Uniview line of POE NVRs. Simply plug the camera into the back of the Uniview NVR and you have instant video on the recorder's HDMI interface. You can also view and manage the NVR through free desktop and mobile apps, such as EZView and EZStation.

ONVIF Compatibility

If you want to add this camera to a security system already set up, that’s no problem. This camera complies with the protocols set by the Open Network Video Interface Forum (ONVIF). This means, as long as your current recorder is ONVIF compatible, you’ll be able to set this camera up with your current system.

Related Videos


SPECIFICATION Download PDF
Camera Type IP
Form Factor Dome
Resolution 4MP
Max Resolution 2688 x 1520
Frames Per Second 30 FPS
Image Sensor 1/2.7", Progressive Scan, CMOS
Lens Type Fixed Lens
Focal Length 2.8mm
Field of View 101.1°
Illumination Infrared
IR Range Up to 100ft
Video Compression Ultra H.265|H.265|H.264
Max Video Bitrate 16Mbps
Audio Built-in Microphone
Onvif Compatible Yes
Onboard Storage Up to 256GB
Power Supply DC12V|POE
Power Consumption Max 4.5W
Operating Temperature -22°F ~ 131°F
Weight .49 Lbs
SOFTWARE
Name Description Version Download
EZ Station Unified management for Uniview IP Cameras and NVRs. Versionv1130.3.12.0 DownloadDownload
EZ Tools Uniview tool kit for device search and upgrade, remote configuration, recording time and capacity calculation. Versionv1122.2.6.0 DownloadDownload
EZ Player Media player for local recordings. Versionv1111.1.3.0 DownloadDownload
Windows Plugin This is the web plugin for Windows. After installation, you will be able to live view most of Uniview IPC/NVR on IE for Windows. Version DownloadDownload
EZ Station Unified management for Uniview IP Cameras and NVRs. Versionv1113.3.10.1 DownloadDownload
MAC Plugin This is the web plugin for Mac OS. After installation, you will be able to live view most of Uniview IPC/NVR on Safari for Mac. Version DownloadDownload
