UNV 4MP Dark Grey IP Weatherproof IR Turret Camera with Built-in Mic and 2.8mm Fixed Lens (IPC3614SR3-ADF28K-G-BK)
Translation missing: en.products.product.sku: SKU# 3500
Order within to ship- Regular price
- $309.00
- Sale price
- $309.00
- Regular price
-
Couldn't load pickup availability
- Day/night functionality
- Up to 120dB WDR (Wide Dynamic Range)
- Smart IR, up to 30m (98ft) IR distance
- Ultra 265, H.264, MJPEG
- Triple streams
- ONVIF Conformance
- Wide temperature range: -30°C ~ 60°C (-22°F ~ 140°F)
- Wide voltage range of ±25%
- Micro SD, up to 256 GB
- Built-in Mic
- 2KV surge protection designed for network interface
- IP67
- 3-Axis
You may want these accessories for this product
UNV Wall Mount for Dome Security C...
UNV Wall Mount W/ Junction Box for...
UNV Pole Mount Adapter (TR-UP06-IN)
UNV Fixed Dome Indoor Pendant Moun...
UNV 400mm Extender for PTZ Dome Pe...
UNV Waterproof Cable Joint (TR-A01...
UNV Junction Box for Fixed Lens Do...
UNV Corner Bracket Mount for Bulle...
4MP
HD resolution
2.8mm
Fixed Lens
IP67
Weatherproof Rating
Up to 100ft
Night Vision IR Range
3 Year Warranty
Warranty Information
- Day/night functionality
- Up to 120dB WDR (Wide Dynamic Range)
- Smart IR, up to 30m (98ft) IR distance
- Ultra 265, H.264, MJPEG
- Triple streams
- ONVIF Conformance
- Wide temperature range: -30°C ~ 60°C (-22°F ~ 140°F)
- Wide voltage range of ±25%
- Micro SD, up to 256 GB
- Built-in Mic
- 2KV surge protection designed for network interface
- IP67
- 3-Axis
- Day/night functionality
- Up to 120dB WDR (Wide Dynamic Range)
- Smart IR, up to 30m (98ft) IR distance
- Ultra 265, H.264, MJPEG
- Triple streams
- ONVIF Conformance
- Wide temperature range: -30°C ~ 60°C (-22°F ~ 140°F)
- Wide voltage range of ±25%
- Micro SD, up to 256 GB
- Built-in Mic
- 2KV surge protection designed for network interface
- IP67
- 3-Axis
4MP HD RESOLUTION
The captures video up to a resolution of 4MP @ 25 FPS, which is 2688 x 1520 pixels. Every pixel added to your camera's picture gives you a higher quality and more details. So at 4MP, your going to get a crisper, cleaner, and more detailed image.
2.8mm Fixed Lens
The has a 2.8mm Fixed Lens. That means it's fixed at one length: it can't optically zoom in and out. The longer the focal length on a fixed lens camera, the more zoomed in it is and the more close-up detail you'll be able to see. But the shorter the focal length, the wider the field of view and the more area your surveillance will cover.
The has a horizontal field of view of 101.1°.
Built-in Microphone
Having audio capabilities in your video surveillance system can be an important feature. The comes with a built-in microphone, allowing you to hear and record crisp, clear audio without running any additional cables to power a microphone.
NDAA Compliant
This model is compliant with the NDAA (National Defense Authorization Act), meaning it's safe to use and install on U.S. government properties. It was constructed with trusted and reliable technology at its core.
IP67 Weatherproof rating
This camera has an Ingress Protection (IP) rating of 67. This means the camera is completely protected from dust and other solid particles. It can also withstand being submerged in 3 feet of water for up to 30 minutes.
Rest assured that when you install your camera outside, it will have no problem braving the toughest of storms.
Up to 100ft NIGHT VISION IR RANGE
When the sun goes down or the lights go out, this camera switches on it's own onboard infrared LED lights. Theses lights, which are invisible to the human eye, allow the camera to continue functioning and recording video 24/7, day or night. And since its IR range covers Up to 100ft, you're not going to miss anything that happens on your camera's feeds, even if it happens in pitch-black darkness.
Remote access Uniview
The is part of the Uniview line of products. As such it's packed withfeatures that would please a power user, yet it's simple enough to operate for a novice. Easily view and manage your cameras and recorders anywhere in the world with the free mobile and desktop applications. For the power user, this app gives you the power to adjust advanced settings on fly. For the novice, you can use the apps to simply view live feeds and play back recorded video.
Plug & play
If you're creating a new system out of our Uniview cameras, set up is insanely easy with our Uniview line of POE NVRs. Simply plug the camera into the back of the Uniview NVR and you have instant video on the recorder's HDMI interface. You can also view and manage the NVR through free desktop and mobile apps, such as EZView and EZStation.
ONVIF Compatibility
If you want to add this camera to a security system already set up, that’s no problem. This camera complies with the protocols set by the Open Network Video Interface Forum (ONVIF). This means, as long as your current recorder is ONVIF compatible, you’ll be able to set this camera up with your current system.
| SPECIFICATION | ||
|---|---|---|
| Camera Type | IP | |
| Form Factor | Turret | |
| Resolution | 4MP | |
| Max Resolution | 2688 x 1520 | |
| Frames Per Second | 25 FPS | |
| Image Sensor | 1/3", 4.0 megapixel, progressive scan, CMOS | |
| Lens Type | Fixed Lens | |
| Focal Length | 2.8mm | |
| Field of View | 101.1° | |
| Illumination | Infrared | |
| IR Range | Up to 100ft | |
| Video Compression | Ultra H.265|H.265|H.264 | |
| Max Video Bitrate | 16Mbps | |
| Weatherproof Rating | IP67 | |
| Audio | Built-in Microphone | |
| Onvif Compatible | No | |
| Intelligent Events | Cross Line Detection|Intrusion Detection | |
| Power Supply | DC12V|POE | |
| Power Consumption | Max 5.5W | |
| Operating Temperature | -22°F ~ 140°F (-30°C ~ 60°C) | |
| Weight | 0.33kg | |
| Video Compression | Ultra H.265|H.265|H.264 | |
| Onvif Compatible | Yes | |
| Power Supply | DC12V|POE | |
| Power Consumption | Max 5.5W | |
| Operating Temperature | -22°F ~ 140°F (-30°C ~ 60°C) | |
| Weight | 0.33kg |
| SOFTWARE | |||
|---|---|---|---|
| Name | Description | Version | Download |
| EZ Station | Unified management for Uniview IP Cameras and NVRs. | Versionv1130.3.12.0  |
DownloadDownload |
| EZ Tools | Uniview tool kit for device search and upgrade, remote configuration, recording time and capacity calculation. | Versionv1122.2.6.0 |
DownloadDownload |
| EZ Player | Media player for local recordings. | Versionv1111.1.3.0 |
DownloadDownload |
| Windows Plugin | This is the web plugin for Windows. After installation, you will be able to live view most of Uniview IPC/NVR on IE for Windows. | Version |
DownloadDownload |
| EZ Station | Unified management for Uniview IP Cameras and NVRs. | Versionv1113.3.10.1  |
DownloadDownload |
| MAC Plugin | This is the web plugin for Mac OS. After installation, you will be able to live view most of Uniview IPC/NVR on Safari for Mac. | Version |
DownloadDownload |
