L-Series 4K Ultra HD 32-Channel NDAA-Compliant IP Network Video Recorder with 4 SATA Hard Drive Bays (NVR-4B32L)

|

SKU# 3934

Order within to ship
$499.99
$499.99
$509.99
Shipping calculated at checkout.
Please note, 60-Day Returns are voided if you are enrolled in our branding program and will be branding this product with your company logo.

NVR-4B32L

Recorder

4K Ultra HD

Up to 4K Ultra HD Resolution

4 SATA HDD

Up to 10TB

24 POE Ports

Easy Plug-and-Play

2-Year Warranty

Warranty Information

Characteristics
  • Records IP Cameras up to 4K (8MP) Resolution
  • Max 32 Channel IP Camera Connections w/ 24 POE Ports
  • Simple and straightforward user interface
  • Max 320Mbs Recording Bandwidth
  • 4 SATA HDD interface up to 10TB each
  • NDAA-Compliant
  • ONVIF Compatible
Characteristics
  • Records IP Cameras up to 4K (8MP) Resolution
  • Max 32 Channel IP Camera Connections w/ 24 POE Ports
  • Simple and straightforward user interface
  • Max 320Mbs Recording Bandwidth
  • 4 SATA HDD interface up to 10TB each
  • NDAA-Compliant
  • ONVIF Compatible
Video recorders are the heart of your cctv system. With the NVR-4B32L you can be sure that your security cameras are in good hands. This IP video recorder is perfect for larger installations with up to 32 security cameras.

The NVR-4B32L is just what your system needs to ensure fast, powerful, and reliable surveillance 24/7.

Easy Plug-and-Play Interface

Connect up to 24 IP cameras to the integrated Power-over-Ethernet (PoE) ports for a truly plug-and-play surveillance experience. Each security camera only requires a single ethernet cable to connect it to the NVR thanks to PoE technology.

This all-in-one ethernet cable provides both power and video transmission to the camera up to 300ft. This means that you won't need to run a separate power cable to your cameras, making installation much easier!

Recording Schedules

If you want 24/7 video recording, the NVR-4B32L NVR is a great choice. You can rest assured that your surveillance system never misses a moment with it's ability to add 4 Hard Drive/s, Up to 10TB.

You can also setup custom recording schedules based on days and times of the week, or based on events such as motion detection.

NDAA Compliant

This model is compliant with the NDAA (National Defense Authorization Act), meaning it's safe to use and install on U.S. government properties. It was constructed with trusted and reliable technology at its core.


SPECIFICATION
IP Channels 32
Max Resolution 4K Ultra HD
Max Incoming Bandwidth 320Mbps
Max Outgoing Bandwidth 160Mbps
Video Compression H265 / H264 / H265+ / H264+
Hard Drive Slots 4
Hard Drive Capacity Up to 10TB
Audio I/O 1 input / 1 output
Alarm I/O 16ch / 4ch
Onvif Compatible Yes
Power Supply DC48V
Power Consumption ≤20W
Operating Temperature 14°F ~ 122°F
Dimensions 17.32 × 14.65 × 2.72 in
Weight 13.5lbs
SOFTWARE
Name Description Version Download
Name Search Tool Search for online devices. Version v1.5.4.241107 DownloadDownload
Name VMS247 View multiple cameras and NVRs from your Windows PC. Version v24.2.3.240926 DownloadDownload
