Dascom DC-2300 Card Printer
Translation missing: en.products.product.sku: SKU# DC-2300-YY
Couldn't load pickup availability
Based on a robust metal frame, the printer impresses with its compact design, which only requires a small footprint – regardless of whether you need a single or a dual side version. This makes it small on your desk and thanks to its low noise level it is ideal for use in office environments. But don’t let its size fool you – it can hold up to 100 cards and print them without user intervention. There is a front exit hopper for 30 cards and a rear exit hopper for 70 cards with automatic switching. And with a printing speed of up to 180 cards per hour (YMCKO) or 900 monochrome cards per hour, even larger print jobs are processed quickly.
Print method Direct thermal technology
Resolution up to 300 x 1200 dpi
Print speed Single Side: 180 cards/hour | Dual Side: 135 cards/hour
Card types PVC, PET, PET-G, ISO ID-1/CR-80 format (85.6 x 53.98 mm or 3.375 x 2.125 inches)
Interfaces USB (2.0), Ethernet (10/100)
Card thickness 0.25 – 1.25 mm (10 to 50 mil)
Security features RFID ribbon, custom watermarks
Weight 6.2 kg (13.66 lb) approximately
Driver Windows 32 and 64 Bit
Excellent Print Quality and Watermarks
Thanks to the high resolution of the printer, micro-fonts, complex barcodes, and detailed images can be reproduced with high quality. With the use of “O” or “H” ribbons, individual watermarks and logos can be implemented quickly and inexpensively as an additional security feature.
High Productivity and Easy Handling
With an output of 180 (DC-2300), 220 (DC-3300) or 144 (DC-7600) cards per hour for single-sided color printing, the DASCOM printers are most suitable for medium to large-scale batches. It is very easy to add materials. Both the YMCK color ribbons as well as the transfer ribbon on the DC-7600 are ideally coordinated to each other, and thereby allow unsupervised printing of up to 500 cards.
Easy Connection
The printers have a USB interface as standard. The standard equipment also includes an Ethernet interface, which allows connection to a network.
Creating Cards
With the free basic version of the DASCOM CardEditor software, diverse card designs can be easily created and printed. With the professional version, they can also be linked to databases.
Wide Range of Cards
The DC-7600 can process cards made of different materials – PVC, PET, polycarbonate as well as ABS. With dimensions of 85.6 x 53.98 mm / 3.375 x 2.125 in popular ISO ID-1/CR-80 formats can be processed while the smoothing device provides perfect surfaces, even on uneven cards.
Lamination
The DC-5100 laminator is also available and can be used either stand-alone or connected to the DC-7600.
