4K UltraHD Wide Angle Weatherproof Bullet IP Security Camera with a 1.68mm Fixed Lens (U1-8MP-180BT1)
Translation missing: en.products.product.sku: SKU# 3789NB
Order within to ship- Regular price
- $709.00
- Sale price
- $709.00
- Regular price
-
Couldn't load pickup availability
- High quality image with 8MP, 1/2.7"CMOS sensor
- 8MP (3840*2160) @30/25fps; 5MP (3072*1728)@30/25fps; 4MP(2560*1440) @30/25fps; 2MP (1920*1080) @30/25fps; s
- Wide Angle technology realize the horizontal viewing angle of 180°
- The dewarp level can be configured in the range of 1-9
- Ultra 265,H.264,H.265, MJPEG
- Smart intrusion prevention, include cross line, intrusion, enter area, leave area detection
- Based on target classification, smart intrusion prevention significantly reduce false alarm caused by leaves, birds and lights etc., accurately focus on human and, motor vehicle and non-motor vehicle
- 120dB true WDR technology enables clear image in strong light scene
- Auto Scene Match (ASM)（Only WDR
- Built-in Mic
- Smart IR, up to 20m (66ft) IR distance
- Supports 256 GB Micro SD card
- IP67 protection
Choose a version
Choose between the Retail and Blank version of this product.
- UNV Retail versions come with the standard Uniview Product that has a Uniview Logo and Uniview Color Box.
- UNV Blank versions are Uniview product without any Uniview Logos on the product or the box. Only choose this option if you are one of our branding program customers.
UNV Retail
You may want these accessories for this product
UNV Junction Box for Fixed Lens Bu...
UNV Pole Mount Adapter for Fixed L...
UNV Waterproof Cable Joint (TR-A01...
UNV Corner Bracket Mount for Bulle...
U1-8MP-180BT1
IP Security Camera
4K
Ultra HD resolution
1.68mm
Fixed Lens
IP67
Weatherproof Rating
Up to 65ft
Night Vision IR Range
3 Year Warranty
Warranty Information
- High quality image with 8MP, 1/2.7"CMOS sensor
- 8MP (3840*2160) @30/25fps; 5MP (3072*1728)@30/25fps; 4MP(2560*1440) @30/25fps; 2MP (1920*1080) @30/25fps; s
- Wide Angle technology realize the horizontal viewing angle of 180°
- The dewarp level can be configured in the range of 1-9
- Ultra 265,H.264,H.265, MJPEG
- Smart intrusion prevention, include cross line, intrusion, enter area, leave area detection
- Based on target classification, smart intrusion prevention significantly reduce false alarm caused by leaves, birds and lights etc., accurately focus on human and, motor vehicle and non-motor vehicle
- 120dB true WDR technology enables clear image in strong light scene
- Auto Scene Match (ASM)（Only WDR
- Built-in Mic
- Smart IR, up to 20m (66ft) IR distance
- Supports 256 GB Micro SD card
- IP67 protection
- High quality image with 8MP, 1/2.7"CMOS sensor
- 8MP (3840*2160) @30/25fps; 5MP (3072*1728)@30/25fps; 4MP(2560*1440) @30/25fps; 2MP (1920*1080) @30/25fps; s
- Wide Angle technology realize the horizontal viewing angle of 180°
- The dewarp level can be configured in the range of 1-9
- Ultra 265,H.264,H.265, MJPEG
- Smart intrusion prevention, include cross line, intrusion, enter area, leave area detection
- Based on target classification, smart intrusion prevention significantly reduce false alarm caused by leaves, birds and lights etc., accurately focus on human and, motor vehicle and non-motor vehicle
- 120dB true WDR technology enables clear image in strong light scene
- Auto Scene Match (ASM)（Only WDR
- Built-in Mic
- Smart IR, up to 20m (66ft) IR distance
- Supports 256 GB Micro SD card
- IP67 protection
4K HD RESOLUTION
The U1-8MP-180BT1 captures video up to a resolution of 4K @ 30 FPS, which is 3840 x 2160 pixels. Every pixel added to your camera's picture gives you a higher quality and more details. So at 4K, your going to get a crisper, cleaner, and more detailed image.
1.68mm Fixed Lens
The U1-8MP-180BT1 has a 1.68mm Fixed Lens. That means it's fixed at one length: it can't optically zoom in and out. The longer the focal length on a fixed lens camera, the more zoomed in it is and the more close-up detail you'll be able to see. But the shorter the focal length, the wider the field of view and the more area your surveillance will cover.
The U1-8MP-180BT1 has a horizontal field of view of 180°.
Artificial Intelligence
With artificial intelligence, the U1-8MP-180BT1 adds more reliability to your surveillance system, since you don't have to worry about false alarms. This camera can recognize the difference between important motion and non-important motion and can trigger events accordingly. Save recording space, prevent false alarms, and make your mobile push notifications actually useful.
NDAA Compliant
This model is compliant with the NDAA (National Defense Authorization Act), meaning it's safe to use and install on U.S. government properties. It was constructed with trusted and reliable technology at its core.
IP67 Weatherproof rating
This camera has an Ingress Protection (IP) rating of 67. This means the camera is completely protected from dust and other solid particles. It can also withstand being submerged in 3 feet of water for up to 30 minutes.
Rest assured that when you install your camera outside, it will have no problem braving the toughest of storms.
Up to 65ft NIGHT VISION IR RANGE
When the sun goes down or the lights go out, this camera switches on it's own onboard infrared LED lights. Theses lights, which are invisible to the human eye, allow the camera to continue functioning and recording video 24/7, day or night. And since its IR range covers Up to 65ft, you're not going to miss anything that happens on your camera's feeds, even if it happens in pitch-black darkness.
Remote access Uniview NB
The U1-8MP-180BT1 is a part of our VIVOTEK brandable line of products. As such, it's packed with features that would please a power user, yet it's simple enough to operate for a novice. Easily view and manage your cameras and recorders anywhere in the world with the free mobile and desktop applications. For the power user, these apps give you the power to adjust advanced settings on the fly. For the novice, you can use the apps to simply view live feeds and play back recorded video. Whatever you need to accomplish, it's all right there at your fingertips.
Plug & play
If you're creating a new system out of our VIVOTEK brandable cameras, set up is insanely easy with our VIVOTEK line of POE NVRs. Simply plug the camera into the back of the VIVOTEK NVR and you have instant video on the recorder's HDMI interface. You can also view and manage the NVR through free desktop and mobile apps, such as Vast 2 and VIVOcloud.
ONVIF Compatibility
If you want to add this camera to a security system already set up, that’s no problem. This camera complies with the protocols set by the Open Network Video Interface Forum (ONVIF). This means, as long as your current recorder is ONVIF compatible, you’ll be able to set this camera up with your current system.
| SPECIFICATION | ||
|---|---|---|
| Camera Type | IP | |
| Form Factor | Bullet | |
| Resolution | 4K | |
| Max Resolution | 3840 x 2160 | |
| Frames Per Second | 30 FPS | |
| Image Sensor | 1/2.7", 8.0 megapixel, progressive scan, CMOS | |
| Lens Type | Fixed Lens | |
| Focal Length | 1.68mm | |
| Field of View | 180° | |
| Illumination | Infrared | |
| IR Range | Up to 65ft | |
| Video Compression | Ultra H.265|H.265|H.264 | |
| Max Video Bitrate | 16Mbps | |
| Weatherproof Rating | IP67 | |
| Onvif Compatible | No | |
| Artificial Intelligence | No | |
| Onboard Storage | Up to 256GB | |
| Power Supply | DC12V|POE | |
| Power Consumption | Max 7W | |
| Operating Temperature | -30°C ~ 60°C (-22°F ~ 140°F) | |
| Weight | 0.43kg (0.94lb) | |
| Video Compression | Ultra H.265|H.265|H.264 | |
| Onvif Compatible | Yes | |
| Power Supply | DC12V|POE | |
| Power Consumption | Max 7W | |
| Operating Temperature | -30°C ~ 60°C (-22°F ~ 140°F) | |
| Weight | 0.43kg (0.94lb) |
| SOFTWARE | |||
|---|---|---|---|
| Name | Description | Version | Download |
| Name Guard Station | Unified management for IP Cameras and NVRs. | Version v1130.3.12.1  |
DownloadDownload |
| Name Guard Tools | Tool kit for device search and upgrade, remote configuration, recording time and capacity calculation. | Version v1103 |
DownloadDownload |
| Name Guard Player | Media player for local recordings. | Version v1111.1.1.0 |
DownloadDownload |
| Name Guard Station | Unified management for IP Cameras and NVRs. | Versionv1113.3.10.1  < |
DownloadDownload |
