U1-5MP-TG2T1

Tri-Guard 2.0 5MP Red/Blue Active Deterrence Lights, White Light, and IR LED Turret IP Security Camera with a 2.8mm Lens and Two-Way Audio

Tri-Guard 2.0 5MP Red/Blue Active Deterrence Lights, White Light, and IR LED Turret IP Security Camera with a 2.8mm Lens and Two-Way Audio (U1-5MP-TG2T1)
  • High quality image with 5MP, 1/2.7"CMOS sensor
  • 5MP (2880*1620)@ 30/25(default)fps; 4MP (2560*1440)@ 30/25fps; 3MP (2304*1296) @30/25fps; 2MP (1920*1080) @30/25fps
  • Ultra 265, H.265, H.264, MJPEG
  • Intelligent perimeter protection, include cross line, intrusion, enter area, leave area detection
  • Based on target classification, smart intrusion prevention significantly reduce false alarm caused by leaves, birds and lights etc., accurately focus on human and, motor vehicle and non-motor vehicle
  • Intelligent People Flow Counting and Crowd Density Monitoring
  • Auto Scene Match (ASM)（Only WDR)
  • 130dB true WDR technology enables clear image in strong light scene
  • Support red & blue warning light
  • Support 9:16 Corridor Mode
  • Alarm:1 in/1 out, Audio: 1 in/1 out, Built-in Mic and Speaker
  • Smart IR, up to 30m (98.4 ft) IR distance
  • Supports 256 G Micro SD card
  • P67 protection
Product Specifications
Camera Type IP
Form Factor Turret
Resolution 5MP
Max Resolution 2880 x 1620
Frames Per Second 30 FPS
Image Sensor 5MP, 1/2.7" CMOS sensor
Lens Type Fixed Lens
Focal Length 2.8mm
Field of View 109°
Illumination Type Infrared or Color Mode
IR Range Up to 100ft
Video Compression Ultra H.265|H.265|H.264
Weatherproof Rating IP67
Video Bitrate 16Mbps
Onvif Compatible Yes
Artificial Intelligence Yes
Power Supply DC12V|POE
Power Consumption 10W
Operating Temperature -30°C ~ 60°C (-22°F ~ 140°F)
Weight 0.69kg (1.53lb)
