U1-4MP-T1G
4MP IP Weatherproof IR Turret Camera with Built-in Mic and 2.8mm Fixed Lens
- Day/night functionality
- Up to 120dB WDR (Wide Dynamic Range)
- Smart IR, up to 30m (98ft) IR distance
- Ultra 265, H.264, MJPEG
- Triple streams
- ONVIF Conformance
- Wide temperature range: -30°C ~ 60°C (-22°F ~ 140°F)
- Wide voltage range of ±25%
- Micro SD, up to 256 GB
- Built-in Mic
- 2KV surge protection designed for network interface
- IP67
- 3-Axis
| Product Specifications | |
|---|---|
| Camera Type | IP |
| Form Factor | Turret |
| Resolution | 4MP |
| Max Resolution | 2688 x 1520 |
| Frames Per Second | 25 FPS |
| Image Sensor | 1/3", 4.0 megapixel, progressive scan, CMOS |
| Lens Type | Fixed Lens |
| Focal Length | 2.8mm |
| Field of View | 101.1° |
| Illumination Type | Infrared |
| IR Range | Up to 100ft |
| Video Compression | Ultra H.265|H.265|H.264 |
| Weatherproof Rating | IP67 |
| Video Bitrate | 16Mbps |
| Onvif Compatible | Yes |
| Power Supply | DC12V|POE |
| Power Consumption | Max 5.5W |
| Operating Temperature | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
| Weight | 0.33kg |
